1981 Suzuki PE125
Specifications and workshop reference information for the 1981 Suzuki PE125, including engine, chassis, service data and setup details.
Note: Specs are compiled from factory data, manuals and owner feedback. Bikes vary — if yours is different, jump into the forum and share it.
General Specifications
| Engine Type | Air-cooled 2-stroke single-cylinder piston reed valve |
| Displacement | 123 cc |
| Bore × Stroke | 56.0 × 50.0 mm |
| Compression Ratio | 6.8:1 |
| Maximum Power | 17 hp |
| Maximum Torque | 15 Nm |
| Carburetor | Mikuni VM24SS |
| Lubrication | Suzuki CCI oil injection |
| Fuel Mix Ratio | |
| Ignition | CDI magneto |
| Spark Plug | NGK B8ES |
| Spark Plug Gap | 0.6 – 0.7 mm |
Transmission
| Transmission Type | 6-speed manual |
| Clutch | Wet multi-plate |
| Primary Reduction | 3.181 |
| Final Reduction | 3.857 |
| Overall Reduction | 12.27 |
Dimensions
| Overall Length | 2090 mm |
| Overall Width | 865 mm |
| Overall Height | 1170 mm |
| Wheelbase | 1370 mm |
| Ground Clearance | 265 mm |
| Fuel Tank Capacity | 9.5 L |
Chassis
| Frame Type | Steel single cradle |
| Caster Angle | 28° |
| Trail | 112 mm |
| Front Suspension | Telescopic forks |
| Rear Suspension | Twin shock swingarm |
| Front Suspension Travel | 190 mm |
| Rear Suspension Travel | 110 mm |
Brakes & Wheels
| Front Tire | 2.75-21 |
| Rear Tire | 4.10-18 |
| Front Brake | Drum brake |
| Rear Brake | Drum brake |
